Trek FX 1 Stepover Gen 4 - Era White

The FX 1 is a versatile, sleek hybrid bike engineered for everyday recreation, fitness tracking, and local city commuting. Built around the same lightweight Alpha Gold Aluminium frame design shared across the premium FX range, it utilizes an incredibly strong steel fork and an easy-to-use 2x8 speed Shimano drivetrain to deliver an ultra-wide range of gears for tackling hills. Paired with mechanical disc brakes for crisp, predictable stopping power in both wet and dry weather, the FX 1 comes completely ready to be configured with commuter racks, mudguards, and fitness accessories to conquer whatever your daily route looks like.

Specifications

Frameset & Geometry

• Frame: Alpha Gold Aluminium, internal cable routing, flat-mount disc brake interface, integrated kickstand mount, 135x5mm quick-release dropout. Fully equipped with integrated rack and mudguard (fender) mounts.

• Fork: FX Steel, flat-mount disc, lowrider rack mounts, 410mm axle-to-crown height, secure ThruSkew 5mm bolt-on quick-release system.

• Frame Clearance: High-volume compatibility up to 700x40mm maximum tyre size (without mudguards).

Drivetrain & Shifting (Shimano 2x8 Multi-Range Layout)

• Shifters: Shimano EF500 integrated brake lever and mechanical pod assembly, 2x8 speed setup.

• Front Derailleur: Shimano Tourney TY606, 31.8mm/34.9mm clamp diameter, top-swing, dual-pull design.

• Rear Derailleur: Shimano Acera (M3020-8) 8-speed derailleur (handles up to a 40T max cog).

• Cassette: Shimano 8-speed, 12-32T ratio profile.

• Chain: KMC Z8.3 indexing chain.

• Crankset: Forged alloy arms, 170mm length, fitted with a 46/30T double chainring setup.

• Bottom Bracket: Sealed cartridge unit, 68mm English threaded standard.

• Drivetrain Tuning Limits: Maximum 1x chainring limit: 44T | Maximum 2x chainring limit: 46/32T.

• Pedals: Wellgo nylon platform pedals.

Brakes & Control

• Braking System: Tektro MD-U310 mechanical (cable-actuated) flat-mount disc brake calipers.

• Rotors: Tektro Wave 6-bolt steel disc rotors; 160mm front / 160mm rear (160mm is the maximum permitted frame/fork rotor dimension).

Wheels & Tyres

• Rims: Double-wall alloy construction, 32-hole drilling profile.

• Front Hub: Formula DC-20 alloy shell, 6-bolt rotor mount, 100x5mm spacing with a 139mm bolt-on skewer.

• Rear Hub: Formula DC-22 alloy shell, 6-bolt rotor mount, Shimano 8/9/10-speed freehub body standard, 135x5mm spacing with a 152mm quick-release skewer.

• Tyres: Bontrager H2 Comp, wire bead, 30 TPI casing, 700x35mm fast-rolling street tread.

Cockpit & Finishing Kit

• Handlebars: Bontrager Riser steel handlebar, 25.4mm classic clamp diameter, stable 30mm high-rise profile.

  • Width by Size: S, M, L: 600mm width | XL: 620mm width.

• Grips: Trek Ergonomic Comp, secure lock-on design.

• Stem: Bontrager alloy stem, 25.4mm handlebar clamp, 10-degree rise.

  • Length by Size: S, M: 90mm extension | L, XL: 110mm extension.

• Seatpost: Bontrager alloy micro-adjust post, 27.2mm diameter, comfortable 12mm offset.

  • Length by Size: S, M: 330mm length | L, XL: 400mm length.

• Saddle: Bontrager Sport urban saddle.

Weight & Structural Limits

• Base Build Weight: 13.00 kg / 28.67 lbs (Measured on a Size Medium frame configuration).

• Maximum Weight Capacity: Structural weight limit of 136 kg / 300 lbs total combined mass (includes the combined weight of the bicycle, rider, and all mounted cargo or racks).

Please Note: Components and frame specifications are subject to running factory parts substitutions by the manufacturer based on global availability. Final retail build weights can vary across frame sizing, paint finishes, and protective hardware outfitting.
